Bell 429 - Page 93

BHT-429-MPI
Table1.ScheduledInspections-4-YearInspection(continued)
INITIAL
DATAREFERENCE/IMRR
TASKNUMBER
TASKDESCRIPTIONACCESSZONES
MECHOTHER
429-MM,Chapter63
631001-1
NOTE
Tobeperformedevery4yearsorat
5000hoursofcomponentinspection(task
631002),RestorationoftheMainRotor
TransmissionAssembly,whichevercomes
rst.
2.Doadetailinspectionofthemainrotor
transmissionassembly.
600EL,
600ER,
600FL,
600FR
611
TAILROTORDRIVESYSTEM
429-MM,Chapter65
652001-1
NOTE
Tobeperformedevery4yearsorat
5000hoursofcomponentinspection(task
652003),RestorationoftheTailRotorGear-
boxAssembly,whichevercomesrst.
2.Doadetailinspectionofthetailrotorgearbox
assembly.
500G
ELECTRICALSYSTEM
429-MM,Chapter96
2310LA-03
1.Doadetailedinspectionoftheconnectors
4296P9and4296J9toincludethebackshelland
theL/HIRFbraidsock.
N/A
212
429-MM,Chapter96
2310LA-04
2.Doadetailedinspectionoftheconnectors
4296P10and4296J10toincludethebackshelland
theL/HIRFbraidsock.
N/A
212
429-MM,Chapter96
2430LA-01
3.Doadetailedinspectionoftheconnector
2430A1P1toincludethebackshellandtheL/HIRF
braidsock.
N/A
216
429-MM,Chapter96
2810LA-01
4.Doadetailedinspectionoftheconnectors
4296P1and4296J1toincludethebackshelland
theL/HIRFbraidsock.
N/A
210
429-MM,Chapter96
2810LA-04
5.Doadetailedinspectionoftheconnectors
4296P6and4296J6toincludethebackshelland
theL/HIRFbraidsock.
N/A
212
ZONALINSPECTIONS
100-02B
1.DoageneralvisualinspectionoftheLHand
RHlowernosecompartmentandlowernoseskins
includingtheMX-10WescamcameraortheSX-5
starburstNightsunifeitherkitisinstalled.
N/A
110
100-04
2.Doageneralvisualinspectionoftheuppernose
compartmentexternalskinsandaccesspanels.
N/A
111
100-06
3.Doageneralvisualinspectionoftheexternal
surfacesofthenosecaporradome(100A).
N/A
112
200-06
4.Doageneralvisualinspectionoftheinternal
areasoftheLHcabinarea.
200DL,
200EL
213
200-08
5.Doageneralvisualinspectionoftheinternal
areasoftheRHcabinarea.
200DR,
200ER
214
300-07
6.Doageneralvisualinspectionoftheinternal
areasoftheLHcockpitunderoor,toincludelower
sidebodyandkeelbeam.
200BL,
200CL
313
Applicableto:ALL429-A-05-40-00-11A-281A-A
ECCNEAR993DEC2019-Issue2Page3
