CAUTION
204608
BATTERY ISOLATOR
ISOLATE BATTERY
BEFORE WELDING
Located at the battery isolator switch.
204610
Located at the hydraulic tank pressure gauge.
CAUTION
204609
HYDRAULIC OIL
LEVEL
FILL WITH AUTOMATIC
TRANSMISSION
FLUID ONLY
Located at the hydraulic tank sight glass.
PAYLOAD: 23 000 kg (50 600 lbs)
203318
MAKE
MICHELIN XADN/XADT 29.5 R25
300 44 350 51 350
BRIDGESTONE VKT
29.5 R25 2
HH
350 51 375 54 375 54
51
X X X XXXXXX
MODEL SIZE
FRONT MIDDLE
kPakPa kPa
PSIPSI PSI
REAR
TYRE PRESSURE B40C 6x6
PAYLOAD: 36 500 kg (80 468 lbs)
Located on both sides of the machine at the ar-
ticulation area.
204613
Located on the side window at the park brake.
202721
Located at the machine lifting points.
STOP
Located in the cab, at the engine stop control.
203287
GREASE
POINT
Located at the grease points of the machine.
