870984-01 xi
June 1, 1999
Located in the cab, at the tip lever.
TORQUE ALL WHEEL NUTS TO 650Nm
(480 lb-ft) AFTER THE FIRST 5 HOURS
OF OPERATION AND THEN AFTER 50
HOURS. REPEAT THIS PROCEDURE
IF THE WHEELS ARE CHANGED.
WARNING
204976
Located in the following positions:
One on the small, left side window.
One on the fuel tank.
One on the hydraulic tank.
One on the right side and one on the left side of the
bin, between the rear wheels.
%
MAX
RPM
45% 1L - 830
35% 1L - 1200
25% 1L - 1600
20% 1L - 2000
14% - 1H 2000
10% 2L 1H 2100
7% 3L 2H
2100
5% 4L
-
2100
3% 5L
4H
2100
WARNING
204788
B40C
Located on the windscreen.
WARNING
204662
NO ETHER
ELECTRICAL PRE-HEATER BUILT IN.
PERSONAL INJURY MAY RESULT.
WARNING
DO NOT REMOVE CAP
WHEN ENGINE IS HOT
203298
Located on the radiator.
