The following figure details the controls and instruments on the left side instrument panel.
8 870984-01
June 1, 1999
1. Inter axle differential lock control 6. Headlight switch
2. Low range indicator 7. Windshield wiper/washer switch
3. Longitudinal differential lock indicator 8. Hazards switch
4. Rotating beacon switch (if fitted) 9. Low ratio selector switch
5. Interior light switch
L
X
204990
1
2
3
45678
9
S005103
WARNING
TO CHANGE DROP BOX RATIO
1. STOP MACHINE
2. SELECT NEUTRAL
3. SELECT HIGH OR LOW RANGE
4. SELECT REVERSE THEN
SELECT FORWARD GEAR
H
L
