The following figure details the controls and instruments on the main instrument panel.
870984-01 9
June 1, 1999
S005038
204073
r/min
D
Dia 56
Dia 53
Dia 53
Dia 53
Dia 82
2
x100
REV/MIN
5
10
15
20
25
30
Cels.
50
80
100
120
150
Cels.
40
80
100
120
X100
kPa
0
1
2
3
4
5
!
P
n/min
km/h
10
0
20
30
40
50
60
70
80
0
1/1
1/2
21
20
19
18
16
17
12
3
4
5
6
7
8
9101112131415
1. Tachometer 12. Park brake warning indicator
2. Speedometer 13. Main beam warning indicator
3. Transmission oil temperature gauge 14. Coolant low level warning indicator
4. Fuel gauge 15. Left turn indicator
5. Emergency steering warning indicator 16. Engine oil pressure warning indicator
6. Transmission oil temperature warning indicator 17. Rotating beacon warning indicator (if fitted)
7. Bin up warning indicator 18. Engine oil temperature warning indicator
8. Transmission oil pressure warning indicator 19. Engine overspeed warning indicator
9. Right turn indicator 20. Engine oil pressure gauge
10. Do not shift warning indicator 21. Engine coolant temperature gauge
11. Brake overstroke warning indicator
