Bematech BR200BT User Manual

Handy Wireless Scanner
4
USER MANUAL
Charging the Battery
To charge the battery using the USB cable:
There are two method to charge scanner via USB cable.
 Host USB Power
 Power adaptor
1. Connect the micro USB connector directly to the scanner.
2. Connect the other end of the USB connector to the host to begin charging.
You can also connect the USB cable to an outlet using the power adapter to
charge the battery.
3. The battery begins charging when the scanner LED indicator starts flashing
green. LED turns steady green when charging is complete.
 The scanner will power on automatically when charging.
 Batteries shipped may not be full charged and should be fully
charged for maximum charge capacity.
 Recommended charging environment is temperature in 0°C~35°C (32
° F~95°F).

Bematech BR200BT Specifications

General

Battery voltage	3.7 V
Battery capacity	850 mAh
Power source type	Battery
Type	Handheld bar code reader
Wavelength	617 nm
Sensor type	CCD
Scanner type	1D
Read rate (max)	330 reads/s
Light levels (direct sunlight)	0 - 100000 lx
Linear (1D) barcodes supported	Codabar, Code 128, Code 32, Code 39, Code 93, ITF-14, JAN, U.P.C.
2D (matrix & stacked) barcodes supported	Not supported
Standard interfaces	Bluetooth
Connectivity technology	Wireless
Product color	Black
LED indicators	Yes
Housing material	-
International Protection (IP) code	IP43
Storage temperature (T-T)	-10 - 60 °C
Operating temperature (T-T)	0 - 50 °C
Operating relative humidity (H-H)	5 - 95 %

Weight and Dimensions

Depth	62 mm
Width	147 mm
Height	114.5 mm
Weight	210 g
