Bematech BR200BT User Manual

Handy Wireless Scanner
53
USER MANUAL
Start Of Configuration
Chinese Post Code Parameter Setting
Barcode
Value
Barcode Label
Description
RC05
Chinese post code enable
RD05
Chinese post code disable
DC60
Chinese post code data redundant check=off
DC61
Chinese post code data redundant check=1
DC62
Chinese post code data redundant check=2
DC63
Chinese post code data redundant check=3
SZ01
Chinese post code maximum length setting
SZ02
Chinese post code minimum length setting
SET
Confirm to save this setting (required for reading full
ASCII table and length setting)
End Of Configuration

Bematech BR200BT Specifications

General

Battery voltage	3.7 V
Battery capacity	850 mAh
Power source type	Battery
Type	Handheld bar code reader
Wavelength	617 nm
Sensor type	CCD
Scanner type	1D
Read rate (max)	330 reads/s
Light levels (direct sunlight)	0 - 100000 lx
Linear (1D) barcodes supported	Codabar, Code 128, Code 32, Code 39, Code 93, ITF-14, JAN, U.P.C.
2D (matrix & stacked) barcodes supported	Not supported
Standard interfaces	Bluetooth
Connectivity technology	Wireless
Product color	Black
LED indicators	Yes
Housing material	-
International Protection (IP) code	IP43
Storage temperature (T-T)	-10 - 60 °C
Operating temperature (T-T)	0 - 50 °C
Operating relative humidity (H-H)	5 - 95 %

Weight and Dimensions

Depth	62 mm
Width	147 mm
Height	114.5 mm
Weight	210 g
