Bematech BR200BT User Manual

Handy Wireless Scanner
54
USER MANUAL
Start Of Configuration
MSI/Plessy Parameter Setting
Barcode
Value
Barcode Label
Description
RC14
MSI enable
RD14
MSI disable
DC70
MSI data redundant check= off
DC71
MSI data redundant check=1
DC72
MSI data redundant check=2
DC73
MSI data redundant check=3
MS01
MSI/Plessy maximum length setting
MS02
MSI/Plessy minimum length setting
SET
Confirm to save this setting (required for reading full
ASCII table and length setting)
MS03
MSI/Plessy double check digit calculate but not
transmit
MS04
MSI/Plessy double check digit without calculate and
transmit
MS05
MSI/Plessy double check digit calculate but only first
digit transmit
MS06
MSI/Plessy double check digit calculate and both
transmit
MS07
MSI/Plessy single check digit calculate but without
transmit
MS08
MSI/Plessy single check digit calculate and transmit
End Of Configuration

Bematech BR200BT Specifications

General

Battery voltage	3.7 V
Battery capacity	850 mAh
Power source type	Battery
Type	Handheld bar code reader
Wavelength	617 nm
Sensor type	CCD
Scanner type	1D
Read rate (max)	330 reads/s
Light levels (direct sunlight)	0 - 100000 lx
Linear (1D) barcodes supported	Codabar, Code 128, Code 32, Code 39, Code 93, ITF-14, JAN, U.P.C.
2D (matrix & stacked) barcodes supported	Not supported
Standard interfaces	Bluetooth
Connectivity technology	Wireless
Product color	Black
LED indicators	Yes
Housing material	-
International Protection (IP) code	IP43
Storage temperature (T-T)	-10 - 60 °C
Operating temperature (T-T)	0 - 50 °C
Operating relative humidity (H-H)	5 - 95 %

Weight and Dimensions

Depth	62 mm
Width	147 mm
Height	114.5 mm
Weight	210 g
