Bematech BR200BT User Manual

Handy Wireless Scanner
23
USER MANUAL
Start Of Configuration
Setting Name
1. To change the name displayed when the scanner is discovered, scan the
“Friendly device name set” label. Default name is “BR200BT”.
2. Use the ASCII table in Programming Guide to input the name (Max.12 digits).
3. Scan “Confirm Setting” to store the new name.
Friendly device name set
Change the display name when scanner is
discovered.
Confirm Setting (for address and pin code
setting required)
Wireless Discovery
Use the following settings to show or hide the device from wireless discovery.
Discover enable
Make scanner visible to wireless device.
Discover disable
Make scanner invisible to wireless device.
End Of Configuration

Bematech BR200BT Specifications

General

Battery voltage	3.7 V
Battery capacity	850 mAh
Power source type	Battery
Type	Handheld bar code reader
Wavelength	617 nm
Sensor type	CCD
Scanner type	1D
Read rate (max)	330 reads/s
Light levels (direct sunlight)	0 - 100000 lx
Linear (1D) barcodes supported	Codabar, Code 128, Code 32, Code 39, Code 93, ITF-14, JAN, U.P.C.
2D (matrix & stacked) barcodes supported	Not supported
Standard interfaces	Bluetooth
Connectivity technology	Wireless
Product color	Black
LED indicators	Yes
Housing material	-
International Protection (IP) code	IP43
Storage temperature (T-T)	-10 - 60 °C
Operating temperature (T-T)	0 - 50 °C
Operating relative humidity (H-H)	5 - 95 %

Weight and Dimensions

Depth	62 mm
Width	147 mm
Height	114.5 mm
Weight	210 g
