Bematech BR200BT User Manual

Handy Wireless Scanner
5
USER MANUAL
Power on the Scanner
1. Ensure the battery is fully charged. Please refer to the previous section to
charge the battery.
2. Press and hold the power button for 1 second until a long beep sound is
heard to turn on the scanner.
3. To power off the scanner press and hold the function / off button for 3
second until 2 short beeps are heard.
Power on Power off
Function Button
The function button can be used as the power off key or to call or hide virtual keyboard
when the scanner is connected with iPad, iPhone or other devices (not including Android
devices).
Press function
button to call
or hide the
keyboard

Bematech BR200BT Specifications

General

Battery voltage	3.7 V
Battery capacity	850 mAh
Power source type	Battery
Type	Handheld bar code reader
Wavelength	617 nm
Sensor type	CCD
Scanner type	1D
Read rate (max)	330 reads/s
Light levels (direct sunlight)	0 - 100000 lx
Linear (1D) barcodes supported	Codabar, Code 128, Code 32, Code 39, Code 93, ITF-14, JAN, U.P.C.
2D (matrix & stacked) barcodes supported	Not supported
Standard interfaces	Bluetooth
Connectivity technology	Wireless
Product color	Black
LED indicators	Yes
Housing material	-
International Protection (IP) code	IP43
Storage temperature (T-T)	-10 - 60 °C
Operating temperature (T-T)	0 - 50 °C
Operating relative humidity (H-H)	5 - 95 %

Weight and Dimensions

Depth	62 mm
Width	147 mm
Height	114.5 mm
Weight	210 g
