Bematech BR200BT User Manual

Handy Wireless Scanner
22
USER MANUAL
Start Of Configuration
Setting Pin Code
1. To change the pin code, use the “Set pin code” setting. Default is “12345678”.
2. Use the ASCII table in Programming Guide to input the new code (must be at
least 4 digits and not more than 8 numeric digits).
3. Scan “Save Setting” to store the pin code.
Set pin code
Set pin code (SPP Master only)
Confirm Setting (for address and pin code setting
required)
Please check the User Manual from your PC for wireless address and pin code.
Deleting pin code
To delete pin code, use the “Delete pin code setting”.
Delete pin code
Delete the stored pin code.
Reset Name
To change the scanner name back to the default name “BR200BT” use the “Default
device name” setting.
Default device name
Change device name back to default “BR200BT”.
End Of Configuration

Bematech BR200BT Specifications

General

Battery voltage	3.7 V
Battery capacity	850 mAh
Power source type	Battery
Type	Handheld bar code reader
Wavelength	617 nm
Sensor type	CCD
Scanner type	1D
Read rate (max)	330 reads/s
Light levels (direct sunlight)	0 - 100000 lx
Linear (1D) barcodes supported	Codabar, Code 128, Code 32, Code 39, Code 93, ITF-14, JAN, U.P.C.
2D (matrix & stacked) barcodes supported	Not supported
Standard interfaces	Bluetooth
Connectivity technology	Wireless
Product color	Black
LED indicators	Yes
Housing material	-
International Protection (IP) code	IP43
Storage temperature (T-T)	-10 - 60 °C
Operating temperature (T-T)	0 - 50 °C
Operating relative humidity (H-H)	5 - 95 %

Weight and Dimensions

Depth	62 mm
Width	147 mm
Height	114.5 mm
Weight	210 g
