Bematech BR200BT User Manual

Handy Wireless Scanner
14
USER MANUAL
Default Parameters
The factory default setting table gives the default settings of all the programmable
parameters. The default settings will be restored whenever the "Reset" programming
label is scanned and the scanner is in programming mode. Default values are highlighted
in grey background in the settings.
Factory Default Setting
Parameter
Default
Radio communication
Wireless host
Dongle
Pairing mode
Unlocked
Data transmit
Normal
Radio protocol timeout
5 seconds
Power off timeout
20 minutes
Encryption
Enable
Dongle Host
RS-232 communication
Baud rate
9600
Parity
none
Data bits
8
Stop bit
1
RTS/CTS
off
Terminator
<CR><LF>
Keyboard Wedge Communication
Terminator
PC/AT
Keyboard
US keyboard
Terminator
Enter(Alpha numeric)
USB Communication
Terminator
Enter
Code mode
Scan code
Keyboard
US keyboard
Wand Emulation
Wand emulation speed
Normal
Data output
Black=high
Pair contact on dongle
Enable
Scanner
Decoder Selection
Default

Bematech BR200BT Specifications

General

Battery voltage	3.7 V
Battery capacity	850 mAh
Power source type	Battery
Type	Handheld bar code reader
Wavelength	617 nm
Sensor type	CCD
Scanner type	1D
Read rate (max)	330 reads/s
Light levels (direct sunlight)	0 - 100000 lx
Linear (1D) barcodes supported	Codabar, Code 128, Code 32, Code 39, Code 93, ITF-14, JAN, U.P.C.
2D (matrix & stacked) barcodes supported	Not supported
Standard interfaces	Bluetooth
Connectivity technology	Wireless
Product color	Black
LED indicators	Yes
Housing material	-
International Protection (IP) code	IP43
Storage temperature (T-T)	-10 - 60 °C
Operating temperature (T-T)	0 - 50 °C
Operating relative humidity (H-H)	5 - 95 %

Weight and Dimensions

Depth	62 mm
Width	147 mm
Height	114.5 mm
Weight	210 g
