Bematech BR200BT User Manual

Handy Wireless Scanner
67
USER MANUAL
Start Of Configuration
GS1 DataBar Parameter Setting
There are 7 kinds of barcodes in the GS1 DataBar family and they are categorized into
three groups. Barcode types in the same group use the same barcodes for setting.
Group
Representative
Contents
Group 1
GS1 DataBar Omnidirectional
(Formally RSS-14)
GS1 DataBar Omnidirectional
GS1 DataBar Truncated
GS1 DataBar Stacked
GS1 DataBar Stacked Omnidirectional
Group 2
GS1 DataBar Limited
(Formally RSS Limited)
GS1 DataBar Limited
Group 3
GS1 DataBar Expanded
(Formally RSS Expanded)
GS1 DataBar Expanded
GS1 DataBar Expanded Stacked
GS1 DataBar Omnidirectional (Formally RSS-14)
Barcode
Value
Barcode Label
Description
RC15
GS1 DataBar Omnidirectional enable
RD15
GS1 DataBar Omnidirectional disable
SS00
Transmit GS1 DataBar Omnidirectional check digit
SS01
Do not transmit GS1 DataBar Omnidirectional check
digit
SS02
Transmit GS1 DataBar Omnidirectional application ID
(01)
SS03
Do not transmit GS1 DataBar Omnidirectional
application ID (01)
SS05
GS1 DataBar Omnidirectional /EAN-128 emulation
enable
SS04
GS1 DataBar Omnidirectional /EAN-128 emulation
disable
End Of Configuration

Bematech BR200BT Specifications

General

Battery voltage	3.7 V
Battery capacity	850 mAh
Power source type	Battery
Type	Handheld bar code reader
Wavelength	617 nm
Sensor type	CCD
Scanner type	1D
Read rate (max)	330 reads/s
Light levels (direct sunlight)	0 - 100000 lx
Linear (1D) barcodes supported	Codabar, Code 128, Code 32, Code 39, Code 93, ITF-14, JAN, U.P.C.
2D (matrix & stacked) barcodes supported	Not supported
Standard interfaces	Bluetooth
Connectivity technology	Wireless
Product color	Black
LED indicators	Yes
Housing material	-
International Protection (IP) code	IP43
Storage temperature (T-T)	-10 - 60 °C
Operating temperature (T-T)	0 - 50 °C
Operating relative humidity (H-H)	5 - 95 %

Weight and Dimensions

Depth	62 mm
Width	147 mm
Height	114.5 mm
Weight	210 g
