Operation and setting
46
IRDH275_D00122_02_M_XXEN/10.2016
Navigation within the menu
Select the desired menu item using the UP/DOWN keys. The selected menu
item is indicated by a flashing cursor. Press the ENTER key to open the associ-
ated sub menu.
Use the UP/DOWN keys again to select the desired parameters. Move the cur-
sor to the edit field by pressing the ENTER key.
If you have reached the end of the main menu list, it will be indicated by the
"Arrow UP" symbol.
Changing the parameters
When password protection is activated, indicated by the symbol "padlock
closed" , the first thing to enter is the correct password before the param-
eters can be changed using the UP/DOWN keys. Entering the correct pass-
word once allows all parameters to be changed as long as you do not leave
the menu.
Changing the parameter usually has an immediate effect on the measuring
and alarm functions. The changed parameter is stored in a volatile memory by
pressing the ENTER or ESC key after returning to the sub menu (flashing cursor
in column 1). During menu operations, all measuring and alarm functions car-
ry on working as usual in the background.
Changing from the menu mode to the standard mode
Pressing the ESC key allows fast changing from the menu mode to the stand-
ard mode. Thus, the menu item "EXIT" need not to be activated. Automatic
switchover from the menu mode to the standard mode takes place when no
key is pressed for approximately 5 minutes in a main or sub menu.
