Page #19 background imageLoading...
Page #19 background image
19
IRDH275_D00122_02_M_XXEN/10.2016
3. Function
3.1 Common characteristics (IRDH275 and IRDH275B)
ISOMETER® for IT AC systems with galvanically connected rectifiers and
for IT DC systems (IT = unearthed systems)
The operating range of the nominal voltage U
n
can be extended via
coupling devices.
Automatic adaptation to the existing system leakage capacitance
measuring principle (European Patent: EP 0 654 673 B1)
Two separately adjustable ranges of the response value1 kΩ…10 MΩ
(Alarm 1, Alarm 2)
Two-line LC display
Connection monitoring (monitoring of the measuring leads)
Automatic device self test
Option "W":
This option provides: improved shock and vibration resistance for use
in ships, on rolling stock and in seismic environment.
3.2 Additional characteristics IRDH275B
Memory with real-time clock to store all alarm messages with date and
time stamp.
BMS interface (BMS protocol) for data exchange with other Bender
devices (RS485 electrically isolated).
Internal disconnection of the ISOMETER from the IT system to be moni-
tored (using a control signal; terminals F1/F2) , e.g. if several
ISOMETERs® are interconnected.
Current output 0(4)…20mA (galvanically separated) in relation to the
measured insulation value.
Remote setting of certain parameters via the Internet
(option; COM460 additionally required)
