7.3.7 D_IMC_R_ISO
This data value represents the mean insulation resistance measured by the IMC.
7.3.8 D_IMC_R_ISO_BIAS
This data value represents the bias/tendency to the location of the insulation fault (error).
This value is only registered when an insulation fault (error) exists and the measured
voltage is
≥ 200 V.
7.3.9 D_IMC_R_ISO_CNT
This data value represents an 8-bit counter that is incremented on every successful
calculation of a new insulation resistance value.
7.3.10 D_IMC_MANUFACT_INDEX
This data value represents an index to a character from the manufacturer's string.
Unit kΩ
Default 0
Resolution 1
Range 0…50,000
Value Description
0 Unknown
1 Fault on HV1_NEG
2 Fault on HV1_POS
Unit Counter value
Default 0
Resolution 1
Range 0…255
Unit Sample
Default 0
Resolution 1
Range 0…60
7.3.11 D_IMC_MANUFACT_DATA
This data value represents the ASCII code of a character from the manufacturer's string.
7.3.12 D_IMC_HV_1
This data value represents the HV between HV_1_POS and HV_1_NEG.
7.3.13 D_IMC_HV_2
This data value represents the HV between HV_2_POS and HV_2_NEG.
7.3.14 D_IMC_VERSION_INDEX
This data value represents the index to the software version of the IMC.
Unit Sample
Default 0
Resolution 1
Range 0…255
Unit V
Default 0
Resolution 1
Range 0…600
Unit V
Default 0
Resolution 1
Range 0…600
Value Description
0 IMC bootloader
1IMC firmware
2IMC firmware ID
3 IMC firmware Hash
