DataData
iso165C_D00154_03_M_XXEN/01.2019
27
Other
Operating mode .....................................................................................................................................Continuous operation
Degree of protection........................................................................................................................................................ IP5K0
Software version
iso165C ............................................................................................................. V1.0 - Release S010 (VIFC: V5.0 , IMC V5.0)
iso165C-1..........................................................................................................V2.0 - Release S010 (VIFC: V10.0 , IMC V5.0)
Mounting
Recommended screws for mounting ....................................................................................................4 x M5 (not included)
Max. tightening torque ................................................................................................................ 2.25 ± 0.25 Nm(XX Ibs-in)
8.2 Ordering data
8.2.1 Accessories
Type Response value range Nominal voltage Supply voltage Art. No.
iso165C
Alarm2 (Error): 30 kΩ…1 MΩ
(default: 55 kΩ);
Alarm1 (Warning): 40 kΩ…2 MΩ
(default: 300 kΩ)
DC 0…600 V DC 12 V B91068175
iso165C
Alarm2 (Error): 30 kΩ…1 MΩ
(customer setting XXX kΩ);
Alarm1 (Warning): 40 kΩ…2 MΩ
(customer setting: XXX kΩ)
DC 0…600 V DC 12 V B91068175C
iso165C-1
Alarm2 (Error): 30 kΩ…1 MΩ
(default: 250 kΩ);
Alarm1 (Warning): 40 kΩ…2 MΩ
(default: 400 kΩ)
DC 0…600 V DC 12 V B91068176
iso165C-1
Alarm2 (Error): 30 kΩ…1 MΩ
(customer setting XXX kΩ);
Alarm1 (Warning): 40 kΩ…2 MΩ
(customer setting: XXX kΩ)
DC 0…600 V DC 12 V B91068176C
Type Art. No.
iso165C connecting kit B91068503
8.3 Standards - corresponding norms and regulations
8.3.1 General
IEC 61557-8 2007-01; IEC 60664-1 2004-04; ISO 6469-3 2001-11; ISO 23273-3 2006-11
8.3.2 EMC
CISPR 25; ISO 7637-2; ISO 11452-4; ISO 11452-2; ISO 11452-8; ISO 10605; IEC 61326-2-4;
IEC 61000-4-4; E1 acc. 72/245/EWG/EEC; ISO 16750-2
8.3.3 Environmental
ISO 16750-1; ISO 20653; ISO 16750-3; IEC 60068-2-14; IEC 60068-2-27; IEC 60068-2-32;
IEC 60068-2-64; ISO 16750-4; IEC 60068-2-1; IEC 60068-2-2; IEC 60068-2-38;
IEC 60068-2-60; IEC 60068-2-78
Normative exclusion
The device has gone through an automotive test procedure in accordance with multi cus-
tomer requirements as outlined by reg. ISO 16750-x. IEC 61557-8 will be fulfilled by creat-
ing an LED warning function and test button at the customer site if necessary.
Subject to change!
The specified standards take into account the edition valid until 01/19 unless otherwise
indicated.
