Bender ISOMETER iso165C - D_Imc_Version; D_Imc_Test_Cnt; D_Vifc_Hv_Relais; D_Vifc_Measure_Mode

Command and data value descriptionsCommand and data value descriptions
iso165C_D00154_03_M_XXEN/01.2019
23
7.3.15 D_IMC_VERSION
This data value represents the software version of the IMC.
7.3.16 D_IMC_TEST_CNT
This data value represents a 16-bit counter that is incremented on every request of
S_IMC_GET_TEST_CNT.
7.3.17 D_VIFC_HV_RELAIS
This data value represents the selected HV relay.
7.3.18 D_VIFC_MEASURE_MODE
This data value represents the state of the insulation measurement and the IMC activity
status.
Value Description
Data3 Minor version
Data4 Major version
Unit Sample
Default 0
Resolution 1
Range 0…65,535
Value Description
0HV_1_NEG relay
1 HV_1_POS relay
100 Unknown
Value Description
0Disabled
1Enabled
100 Unknown
7.3.19 D_VIFC_LOCK_MODE
This data value represents the current state of the ISOMETER® iso165C locking mode.
7.3.20 D_VIFC_LOCK_PWD
This data value represents the password needed to change the locking state of the
ISOMETER® iso165C.
7.3.21 D_VIFC_HV_RELAIS_STATE
This data value represents the switching state of the HV relay.
7.3.22 D_VIFC_VERSION_INDEX
This data value represents the index to the software version of the VIFC.
Value Description
0Unlocked
1Locked
100 Unknown
Value Description
0x0000 Unlock
0xFFFF Lock
Value Description
0 Open
1 Closed
100 Unknown
Value Description
0 VIFC bootloader
1VIFC firmware
100 Unknown
