Command and data value descriptionsCommand and data value descriptions
iso165C_D00154_03_M_XXEN/01.2019
19
7.2.3.4 S_IMC_GET_R_ISO_ERR_THR
This command requests the insulation fault (error) threshold.
7.2.3.5 S_IMC_GET_R_ISO_WRN_THR
This command requests the insulation warning threshold.
7.2.3.6 S_IMC_GET_MEAN_FACTOR
This command requests the mean factor of the insulation resistance mean algorithm.
7.2.3.7 S_IMC_GET_HV_1
This command requests the HV value between HV1_POS and HV1_NEG.
IMD_Request IMD_Response
CMD 0x32 0x32
DataWord1 0 D_IMC_R_ISO_ERR_THR
DataWord2 0 0
IMD_Request IMD_Response
CMD 0x39 0x39
DataWord1 0 D_IMC_R_ISO_WRN_THR
DataWord2 0 0
IMD_Request IMD_Response
CMD 0x3C 0x3C
DataWord1 0 D_IMC_MEAN_FACTOR
DataWord2 0 0
IMD_Request IMD_Response
CMD 0x36 0x36
DataWord1 0 D_IMC_HV_1
DataWord2 0 0
7.2.3.8 S_IMC_GET_HV_2
This command requests the HV value between HV2_POS and HV2_NEG.
7.2.3.9 S_IMC_GET_VERSION
This command requests the software version of the IMC.
7.2.3.10 S_IMC_GET_TEST_CNT
This command requests the insulation monitoring counter value.
7.2.3.11 S_IMC_GET_MANUFACTURER
This command requests manufacturer information.
IMD_Request IMD_Response
CMD 0x3A 0x3A
DataWord1 0 D_IMC_HV_2
DataWord2 0 0
IMD_Request IMD_Response
CMD 0x33 0x33
DataWord1 D_IMC_VERSION_INDEX D_IMC_VERSION_INDEX
DataWord2 0 D_IMC_VERSION
IMD_Request IMD_Response
CMD 0x5A 0x5A
DataWord1 0 D_IMC_TEST_CNT
DataWord2 0 0
IMD_Request IMD_Response
CMD 0x3D 0x3D
DataWord1 D_IMC_MANUFACT_INDEX D_IMC_MANUFACT_INDEX
DataWord2 0 D_IMC_MANUFACT_DATA
