Modbus register assignment of the ISOMETER®
45
isoPV425_D00028_09_M_XXEN/05.2018
( ) = Channel description code (refer to Chapter 8.2)
[ ] = Alarm type (refer to Chapter 8.1.2.2)
1020
to
1023
U
L2e
Voltage (76)
[no alarm]
--- --- ---
1024
to
1027
Fault location
in %
--- (1022)
[no alarm]
--- --- ---
1028
to
1031
R
UGF
Insulation fault
(71)
[no alarm]
--- --- ---
1032
to
1035
Measured value
update counter
--- (1022)
[no alarm]
--- ---
---
Device
fault (115)
[Device
fault]
Register
Property Description Format
Unit
Value range
3000 RW Reserved --- --- ---
3001 RW Reserved --- --- ---
3002 RW Reserved --- --- ---
3003 RW Reserved --- --- ---
3004 RW Reserved --- --- ---
Register
Measured value
Device fault
Without alarm Alarm 1 Alarm 2
