66
DIMENSIONS ARE IN MM
☺
1
4
3
7
5
2
6
REVISION
REV
DESCRIPTION
DATE
EDITED BY
ECO#
C
ADDED 5550486, REPLACED 5590175WITH
5590240, UPDATED TITLE TO REFLECT WHERE
USED, UPDATED NEXT ASSEMBLY
02/25/2010
AC
00333
D
D-001
D-002
D-003
UPDATED TITLE TO REFLECT WHERE USED
UPDATED BOM REVISION
UPDATED NEXT ASSEMBLY
UPDATED NEXT ASSEMBLY
UPDATED NEXT ASSEMBLIES
08/13/2010
02/04/2011
08/17/2012
11/21/2012
AC
TM
TM
TM
00388
00438
00541
00562
E
REPLACED 5550481WITH 5550087, UPDATED
NEXT ASSEMBLIES
10/29/2013
TM
00593
NEXT ASSEMBLY
5250161
5250166
5250181
5250192
ITEM NO
PART NUMBER
DESCRIPTION
QTY
REV
1
5731004
HD/HDS-PX SERIES FLEX TUBE BRACKET
1
B
2
5590240
PUSH BUTTON AIR VALVE
1
A
3
5545024
WASHER M3 x 9mm
2
-
4
5530043
SHCS M3 x 0.5 x 30
2
-
5
5535020
NUT M3 x 0.5 NL
2
-
6
5550486
FTG NPL -02 NPT x -04 F NPT
1
-
7
5550087
FTG -04 COMP x -02 NPT
1
SHEET 1 OF 1
REV
DWG. NO.
A
SIZE
TITLE:
NAME
DATE
CHECKED
DRAWN
SIZE:
MATERIAL:
E
1645 LEMONWOOD DR.
SANTA PAULA, CA 93060
PROPRIETARY AND CONFIDENTIAL
THE INFORMATION CONTAINED IN THIS DRAWING IS
THE SOLE PROPERTY OF
BENDPAK INC.
ANY
REPRODUCTION IN PART OR AS A WHOLE WITHOUT
THE WRITTEN PERMISSION OF
BENDPAK INC.
IS
PROHIBITED.
NOTE: UNLESS OTHERWISE SPECIFIED
.
AC
5215155
HD-PX SERIES FLEX TUBE
BRACKET ASSY
---
---
07/16/2008
DO NOT SCALE DRAWING
1:2
SCALE:
THIRD ANGLE PROJECTION
SEE SHIPPING INSTRUCTIONS FOR FINAL PACKAGING
1.
ASSEMBLE ITEMS AS SHOWN
2.
