65
3
1
6
2
5
4
7
REVISION
REV
DESCRIPTION
DATE
EDITED BY
ECO#
C
C-001
C-002
C-003
REPLACED 5590175 WITH 5590240
UPDATED NEXT ASSEMBLY
UPDATED NEXT ASSEMBLY
UPDATED NEXT ASSEMBLY
03/03/2009
07/15/2009
07/27/2009
09/09/2009
AC
AC
AC
AC
00262
00241
00249
00300
D
D-001
D-010
UPDATED NEXT ASSEMBLY, ADDED 5550486
UPDATED NEXT ASSEMBLY
UPDATED NEXT ASSEMBLIES
02/24/2010
01/21/2011
07/24/2013
AC
TM
TM
00333
00439
00611
E
REPLACED 5550481 WITH 5550087
10/29/2013
TM
00593
ITEM NO
PART NUMBER
DESCRIPTION
QTY
REV
1 5700031
ZERO ANGLE MTG BRACKET
1
C
2 5590240
PUSH BUTTON AIR VALVE
1
A
3 5530043
SHCS M3 x 0.5 x 30
2
-
4 5545024
WASHER M3 x 9mm
2
-
5 5535020
NUT M3 x 0.5 NL
2
-
6 5550087
FTG -04 COMP x -02 NPT
1
-
7 5550486
FTG NPL -02 NPT x -04 F NPT
1
-
NEXT ASSEMBLY
HD/HDS/HDSO
SERIES
5250118
5250249
SHEET 1 OF 1
REV
DWG. NO.
A
SIZE
TITLE:
NAME
DATE
CHECKED
DRAWN
SIZE:
MATERIAL:
E
1645 LEMONWOOD DR.
SANTA PAULA, CA 93060
PROPRIETARY AND CONFIDENTIAL
THE INFORMATION CONTAINED IN THIS DRAWING IS
THE SOLE PROPERTY OF
BENDPAK INC.
ANY
REPRODUCTION IN PART OR AS A WHOLE WITHOUT
THE WRITTEN PERMISSION OF
BENDPAK INC.
IS
PROHIBITED.
NOTE: UNLESS OTHERWISE SPECIFIED
.
ASSEMBLE ITEMS AS SHOWN
1.
AC
DIMENSIONS ARE IN MM
☺
5215096
PUSH BUTTON AIR ASSEMBLY
---
---
3/14/2008
DO NOT SCALE DRAWING
2:3
SCALE:
THIRD ANGLE PROJECTION
