BendPak HDS-27X - 5260602; Sheet1; Drawing View4

DIMENSIONS ARE IN MM
☺
1
2
ITEM NO PART NUMBER DESCRIPTION QTY REV
1 5245086 HDS-27X LIFT SUPERSTRUCTURE 1 G
2 5250175 HDS-27X PARTS BOX 1 M
REVISION
REV DESCRIPTION DATE EDITED BY ECO#
G UPDATED BOM REVISION 01/10/2022 TM 01378
H UPDATED BOM REVISION 05/24/2022 TM 01414
J WAS 107.3 NOW 108.7, UPDATED BOM REVISION 08/09/2022 TM 01436
SHEET 1 OF 3
REV
DWG. NO.
A
SIZE
TITLE:
NAME
DATE
CHECKED
DRAWN
J
1645 LEMONWOOD DR.
SANTA PAULA, CA 93060
PROPRIETARY AND CONFIDENTIAL
THE INFORMATION CONTAINED IN THIS DRAWING IS
THE SOLE PROPERTY OF BENDPAK INC. ANY
REPRODUCTION IN PART OR AS A WHOLE WITHOUT
THE WRITTEN PERMISSION OF BENDPAK INC. IS
PROHIBITED.
NOTE: UNLESS OTHERWISE SPECIFIED .
CA
5260602
HDS-27X PRODUCTION
LIFT VER D (CE CERT)
12/16/2019
DO NOT SCALE DRAWING
1:52
SCALE:
THIRD ANGLE PROJECTION
OR 08/16/2022
REFER TO MODEL FOR ADDITIONAL INFORMATION 1.
SEE SHIPPING INSTRUCTIONS FOR FINAL PACKAGING 2.
SEE COLORS & GRAPHICS FOR LABEL PLACEMENT 3.
