BendPak HDS-27X - Sheet2; Drawing View5; Drawing View6; Drawing View11

2318.0mm
91.260in
8.150in
207.0mm
30.558in
776.2mm
3.980in MAX
101.1mm MAX
69.528in
1766.0mm
4.026in
102.3mm
61.378in
1559.0mm
A
B
8052.0mm
317.008in
3391.0mm
133.504in
3899.0mm
153.504in
317.371in
8061.2mm
372.730in
9467.3mm
21.016in
533.8mm
22.047in
560.0mm
[40.00 MIN - 45.275in MAX]
1016 MIN - 1150mm MAX
58.134in
1476.6mm
DRIVE THRU
FRONT VIEW
4.279in
108.7mm
DETAIL A
SCALE 1 : 15
5.000in
127.0mm
DETAIL B
SCALE 1 : 15
SHEET 2 OF 3
REV
DWG. NO.
A
SIZE
TITLE:
J
1645 LEMONWOOD DR.
SANTA PAULA, CA 93060
5260602
HDS-27X PRODUCTION
LIFT VER D (CE CERT)
1:55
SCALE:
