BendPak HDS-27X - Sheet3; Drawing View7; Alternate Position1; Alternate Position2

69.528in
1766.0mm
RAISED
67.583in
1716.6mm
TOP LOCK
9.528in
242.0mm
LOWERED
20.339in
516.6mm
LOWEST LOCK
SHEET 3 OF 3
REV
DWG. NO.
A
SIZE
TITLE:
J
1645 LEMONWOOD DR.
SANTA PAULA, CA 93060
5260602
HDS-27X PRODUCTION
LIFT VER D (CE CERT)
1:45
SCALE:
DIMENSIONS SHOWN ARE WITH THE LOCK LADDERS ADJUSTED ALL THE WAY UP 1.
