BendPak HDS-27X - 5730077; Sheet1; Drawing View1; Drawing View2

45°
4 PL
32
4 PL
32
4 PL
243
2 PL
243
2 PL
22
4 PL
R 11
4 PL
307
12
307
ISOMETRIC VIEW
FOR REFERENCE ONLY
DO NOT SCALE
REVISION
REV DESCRIPTION DATE EDITED BY ECO#
A PRODUCTION RELEASE, DERIVED FROM 5730026 02/22/2017 TM 00798
B
UPDATED TITLE TO REFLECT WHERE USED,
UPDATED NEXT ASSEMBLIES
05/04/2018 TS 00945
NEXT ASSEMBLY
5600978
5600980
5601141
5601143
SHEET 1 OF 1
REV
DWG. NO.
A
SIZE
TITLE:
NAME
DATE
CHECKED
DRAWN
B
1645 LEMONWOOD DR.
SANTA PAULA, CA 93060
PROPRIETARY AND CONFIDENTIAL
THE INFORMATION CONTAINED IN THIS DRAWING IS
THE SOLE PROPERTY OF BENDPAK INC. ANY
REPRODUCTION IN PART OR AS A WHOLE WITHOUT
THE WRITTEN PERMISSION OF BENDPAK INC. IS
PROHIBITED.
NOTE: UNLESS OTHERWISE SPECIFIED.
TM
DIMENSIONS ARE IN MM
TOLERANCES: MACHINE TO
0 = ±1.5
0.0 = ±0.5
0.00 = ±0.13
ANGULAR: MACHINE TO
0. = ±½
°
SURFACE FINISH 1.6 Ra µm
FOR MACHINED SURFACES
UNLESS OTHERWISE SPECIFIED
5730077
HDS-18/27/40 SERIES
BASE PLATE
DO NOT SCALE DRAWING
1:3
SCALE:
THIRD ANGLE PROJECTION
CA 10/30/2018
BREAK AND DEBURR ALL SHARP EDGES 0.3mm 1.
MATERIAL: HR ASTM A36 OR Q235 GB/T 700 2.
FLAME CUT PERMISSABLE 3.
02/22/2017
