ITEM NO
PART NUMBER
DESCRIPTION
QTY.
REV
1 5595190
CABLE, LIFTING 16mm
5702mm*
-
2 5746061
Ø16 CABLE BUTTON
1
C
3 5746060
Ø16mm THREADED CABLE
CONNECTOR
1
A
4 5535104
NUT M30 x 3.5 NL
1
-
5 5545415
WASHER M30 x 56 FLAT
1
-
REVISION
REV.
DESCRIPTION
DATE
EDITED BY
ECO#
C
C-001
UPDATED TITLE TO REFELCT WHERE USED AND
NEXT ASSEMBLIES
UPDATED NEXT ASSEMBLIES
08/04/2015
09/18/2015
TM
TM
00683
00724
D
UPDATED TITLE TO REFLECT WHERE USED,
UPDATED BOM REVISION
12/20/2017
TM
00909
E
ADDED 5535104 AND 5545415, UPDATED NEXT
ASSEMBLY
07/21/2020
TM
01174
NEXT ASSEMBLY
5250172
5250175
5250286
WHERE USED
HDS-18 SERIES
HDS-27
HDS-27X
SHEET 1 OF 1
REV
DWG. NO.
A
SIZE
TITLE:
NAME
DATE
CHECKED
DRAWN
E
1645 LEMONWOOD DR.
SANTA PAULA, CA 93060
PROPRIETARY AND CONFIDENTIAL
THE INFORMATION CONTAINED IN THIS DRAWING IS
THE SOLE PROPERTY OF
BENDPAK INC.
ANY
REPRODUCTION IN PART OR AS A WHOLE WITHOUT
THE WRITTEN PERMISSION OF
BENDPAK INC.
IS
PROHIBITED.
MT
5595836
HDS-18E/18EA/27 CABLE
ASSEMBLY Ø16 x 5855mm ST
04/19/2011
DO NOT SCALE DRAWING
1:2
SCALE:
THIRD ANGLE PROJECTION
OR
08/28/2020
DIMENSIONS ARE IN MM
TOLERANCES:
0. = ±1.5
0.0 = ±0.5
SURFACE FINISH 1.6 ISO Ra µm
FOR MACHINED SURFACES
UNLESS OTHERWISE
SPECIFIED
NOTE: UNLESS OTHERWISE SPECIFIED
.
FOR ITEM 1 SPECIFICATIONS REFER TO PART SPECIFICATION FORM
1.
LENGTH SHOWN IS AFTER SWAGING
2.
ITEM 1 QTY FOR REFERENCE ONLY
3.
THREAD 5535104 WITH 5545415 ONTO CABLES FOR SHIPMENT
4.
