BendPak LR-60P - Tools Required; Step 1; Selecting Site; Step 2; Floor Requirements; Concrete Specifications

7
STEP 1
(Selecting Site)
Before installing your new lift, check the following:
1. LIFT LOCATION: Always use architects plans when
available. Check layout dimension against floor plan
requirements making sure that adequate space is
available.
2. OVERHEAD OBSTRUCTIONS: The area where the
lift will be located should be free of overhead obstructions
such as heaters, building supports, electrical lines etc.
3. DEFECTIVE FLOOR: Visually inspect the site where
the lift is to be installed and check for cracked or defective
concrete.
4. OPERATING TEMPERATURE. Operate lift only
between temperatures of 41° -104° F.
5. Lift is designed for INDOOR INSTALLATION ONLY
STEP 2
(Floor Requirements)
This lift must be installed on a solid level
concrete floor with no more than 3-degrees of slope.
Failure to do so could cause personal injury or death.
A level floor is suggested for proper use and
installation and level lifting. If a floor is of
questionable slope, consider a survey of the site and/
or the possibility of pouring a new level concrete slab.
t DO NOT install or use this lift on any asphalt surface
or any surface other than concrete.
t DO NOT install or use this lift on expansion seams
or on cracked or defective concrete.
t DO NOT install or use this lift on a second / elevated
floor without first consulting building architect.
t DO NOT install or use this lift outdoors.
CONCRETE SPECIFICATIONS
LIFT MODEL CONCRETE REQUIREMENT
LR-60 3.5” Min Thickness / 2500PSI
LR-60P 3.5” Min Thickness / 2500PSI
TOOLS REQUIRED
tRotary Hammer Drill Or Similar *
t 3/4” Masonry Bit *
t 1-1/4” Masonry Bit *
t Hammer *
t Wrenches:SAE/ Metric*
t Medium Crescent Wrench
t Crow Bar For Shim Installation*
t Lifting Blocks / Stands*
tHydraulic Jack / Lifting Device*
t Medium Screwdriver
t Tape Measure
DANGER!
All models MUST be installed on 2500 PSI concrete only
conforming to the minimum requirements shown above.
New concrete must be adequately cured by at least
28 days minimum.
IMPORTANT NOTICE!
These instructions must be followed to insure proper installation and operation of your lift. Failure
to comply with these instructions can result in serious bodily harm and void product warranty.
Manufacturer will assume no liability for loss or damage of any kind, expressed or implied resulting
from improper installation or use of this product.
PLEASE READ ENTIRE MANUAL PRIOR TO INSTALLATION!
* Required for LR-60
IMPORTANT NOTE:
BendPak lifts are supplied with installation instructions and concrete fasteners meeting the criteria as prescribed
by the American National Standard "Automotive Lifts - Safety Requirements for Construction, Testing, and
Validation" ANSI/ALI ALCTV-2006. Lift buyers are responsible for any special regional structural and/or seismic
anchoring requirements specied by any other agencies and/or codes such as the Uniform Building Code (UBC)
and/or International Building Code (IBC).
