BendPak XPR-9S Service Manual

2985
1
2
REVISION
REV DESCRIPTION DATE EDITED BY ECO#
C
REPLACED 5570110 WITH 5570129 TO REFLECT
INVENTORY, UPDATED TITLE TO REFLECT WHERE
USED
11/24/2014 TM 00673
D
UPDATED TITLE TO REFLECT MARKETING,
UPDATED NEXT ASSEMBLY
12/01/2015 TM 00738
E
UPDATED TITLE TO REFLECT MARKETING,
UPDATED NEXT ASSEMBLY
09/24/2018 CA 01001
ITEM NO PART NUMBER DESCRIPTION QTY REV
1 5570129 Ø6.4 ID HYDRAULIC HOSE 1 A
2 5550325 FTG NPL Ø1/4 CRIMP x -04 JIC 2 A
NEXT ASSEMBLY
5250037
SHEET 1 OF 1
REV
DWG. NO.
A
SIZE
TITLE:
NAME
DATE
CHECKED
DRAWN
E
1645 LEMONWOOD DR.
SANTA PAULA, CA 93060
PROPRIETARY AND CONFIDENTIAL
THE INFORMATION CONTAINED IN THIS DRAWING IS
THE SOLE PROPERTY OF BENDPAK INC. ANY
REPRODUCTION IN PART OR AS A WHOLE WITHOUT
THE WRITTEN PERMISSION OF BENDPAK INC. IS
PROHIBITED.
TM
5570104
XPR-9 HYDRAULIC HOSE
ASSY Ø6.35 x 2985mm DS
11/13/2009
DO NOT SCALE DRAWING
1:2
SCALE:
THIRD ANGLE PROJECTION
CA 09/24/2018
DIMENSIONS ARE IN MM
TOLERANCES:
0. = ±1.5
0.0 = ±1.0
0.00 = ±0.25
0.000 = ±0.13
ANGULAR: MACH 2
°
SURFACE FINISH 1.6 ISO Ra µm
FOR MACHINED SURFACES
UNLESS OTHERWISE SPECIFIED
NOTE: UNLESS OTHERWISE SPECIFIED.
FOR ITEM 1 SPECIFICATIONS REFER TO PART SPECIFICATION FORM 1.
(*)ITEM 1 QTY FOR REFERENCE ONLY 2.

BendPak XPR-9S Specifications

General

Brand	BendPak
Model	XPR-9S
Category	Lifting Systems
Language	English
