Timing chart
The following table shows compatible signal types, their resolution and frequency refresh rates.
Horizontal: 15kHz, 31kHz to 90 kHz, Vertical: 50 Hz to 85 Hz
PC timing
Signal
Type
Resolution
Frame
Rate
Component
BNC
VGA
DVI-D
HDMI/HD
Connect
DisplayPort
RGBHV YUV RGBHV YUV RGB YUV
PC
640x480 59.94 V V V V V
640x480 75 V V V V V
640x480 85 V V V V V
800x600 75 V V V V V
800x600 85.06 V V V V V
848x480 47.95 V V V V V
848x480 59.94 V V V V V
1024x768 60 V V V V V
1024x768 75.03 V V V V V
1024x768 85.03 V V V V V
1280x720 47.95 V V V V V
1280x768 59.87 V V V V V
1280x800 59.81 V V V V V
1280x960 60 V V V V V
1280x1024 60.02 V V V V V
1280x1024 75.02 V V V V V
1280x1024 85.02 V V V V V
1366x768 59.79 V V V V V
1440x900 59.887 V V V V V
1600x1200 60 V V V V V
1920x1080 47.95 V V V V V
1680x1050 59.94 V V V V V
1920X1200
(Reduce
Blanking)
60 V V V V V
1400X1050 60 V V V V V
Apple Mac
640x480 66.59 V V V V V
832x624 74.54 V V V V V
1152x870 75 V
SDTV
1440x480i 60 V V V
1440x576i 50 V V V
