Connections
18
Connecting the touch module
Try either method below to set up the video and touch input:
• Connect the TYPE-C port on the display to a USB Type-C port on the computer
using the supplied USB Type-C cable.
• Connect video cables (HDMI/DP/VGA) and the supplied touch USB cable from a
computer to the corresponding ports of the display.
• HDMI must be used with the TOUCH-USB at the front panel.
• HDMI 1 must be used with DP and the TOUCH-USB next to HDMI 1.
• HDMI 2 must be used with VGA and the TOUCH-USB next to HDMI 2.
TOUCH-USBHDMI1DPTOUCH-USBHDMI2
VGA
TYPE-C
TOUCH-USB
HDMI
or or
or
• The touch module of the display supports easy plug-and-play operation. There is no need to
install additional drivers on the computer.
• Avoid blocking the touch screen frame (where sensors are located) when initiating the touch
module.
• It is highly recommended that you connect the display to the PC or laptop directly. Avoid
connecting the display to a face plate device which may cause failures in touch operations.
• If any ghost image occurs, please try to un-plug and then re-plug all USB cables. If the failure
image still exists, use another USB Type-A to Type-A cable.
