Internal ground terminal
The ground terminal is a tapered hole in the plate, located under
the terminal board at its left.
How to wire the actuator
The wiring must be done according to the wiring diagram of the
actuator.
1. Make sure that the power supply voltage matches the
information on the nameplate located on the side of the
actuator.
2. Separate the female part of the push-on connector from the
male part which is fixed to the board.
3. Using a crimping tool, connect the power supply to the female
push-on connectors.
4. Place back the female connectors on the male connectors
marked L1, L2 & L3 (3Ph) or L, N (1Ph), depending on the
power supply phase.
5. Using a crimping tool, attach the end of the ground cable to
the ring lug
6. Using a 4 mm hex key, secure the ground cable to the ground
terminal.
7. Using a 3×0.5 mm flat-blade screwdriver, connect the control
and signaling wires to terminals 1 to 36.
8. Tighten the sealing nut on the cable gland when the wiring is
complete.
9. Make sure that all cable glands are correctly tightened.
