16.2.1. Pull Compensation
Selecting a Compensation Table
1. Tap the expand-down button to open the drop-down.
o Tapping within the eld will allow the name of any custom table to be edited.
o Wide-Angle Driver osets will be added to the global compensation values when using any
frame that utilized the wide-angle driver.
2. From the list, tap to select the desired table.
Editing a Variable Compensation Table
With a compensation table selected, the values will populate below.
Tap in any eld other than the 0 or ∞ width elds to begin editing.
· Width Range - This is the range that the dierent compensations will aect.
o This range is displayed in points (0.1mm)
The width of the satin stitches are adjusted by percentages and by points (0.1mm).
· Percentage - the width of the satin stitches are multiplied by this value.
· Points - the satin stitch width has this value added to each end of the stitch.
· The values of 100% and 0 points will load the design unaltered.
These stitches can be altered along the X-axis (horizontal stitch direction) and along the Y-axis (vertical stitch
direction).
· If locked together, X and Y will both be changed according to the value entered for X.
· If unlocked, X and Y can be altered independently.
Saving Changes
Changes to the value elds will be saved by any of the following.
· Shifting focus to another eld
· Selecting another table
· Conrming out of the screen
