17. Maintenance
Maintenance Timers
The top portion of the screen is devoted to the maintenance timers. These count down at specic intervals
and prompt you to perform the required maintenance on time or after a specied number of stitches.
Each timer counts down both a specic amount of time and a set number of stitches. When either interval is
reached, the maintenance will be due and the step-through button will pulse yellow.
The timer bars will ll up as time or stitches elapse. This indicates how soon a maintenance timer will be due.
Both the time and stitches can be viewed.
· The Maintenance Timer Bar displays the time elapsed and remaining.
· The Maintenance Timer Bar displays the time elapsed and remaining.
Timer With No Progress
Timer Full - Maintenance Due
Maintenance Step-Throughs
Tapping the Maintenance Step-Through Start button will begin stepping the machine through the
corresponding maintenance procedure.
Each procedure will walk the user through where and how much to lubricate, move the machine to the
proper positions for lubrication, and reset the timer upon completion.
Each screen of the step-throughs will have instructions, images, and buttons on the bottom to proceed
through. Not all buttons will be available on every screen. There are times when the next steps must be
completed before exiting the step-though.
· Go to the Previous Step
