· Go to the Next Step
· Cancel - Exit without completing the step-through.
· Completed - Exit and reset the timer.
· In Spec - the X-cable tension is within the spec - continue to the next step
· Out of Spec - the X-cable tension is out of spec - continue to the next step for adjustment
Machine Information
The machine information displays information about the software, environment, rmware, and the machine
itself.
Much of this information will be useful if speaking with technical support.
Technical Screens
The buttons at the bottom of the screen will open technical screens that deal with dierent facets of the
machine's functionality.
· Head Timing
o Deals with the rotation of the hook and Z position
· Needlecase Calibration
o Stores and manipulates the left-right needle centering
· Sensors
o Shows the current state of the sensors
· Steppers
o Deals with the functions of several motors
Status Log
The status log shows the latest captured action of the machine.
