Bernina Q Series User Manual

Setting up the machine
27
2.6 Bobbin thread
Winding the bobbin
> Place the empty bobbin on the spool axis such that the BERNINA label on the bobbin is not visible.
> Place the spool on the right spool pin.
> Insert the thread first in the eyelet positioned vertically above the spool and then in the right rear eyelet
of the thread guide.
> Guide the thread once around the thread pre-tension(1) in a counterclockwise direction.
> Wind the thread clockwise three or four times around the empty bobbin.
> Pull the excess thread over the thread cutter at the lever (2) and cut.
1
2

Bernina Q Series Specifications

General

Color Touch Screen	Yes
LED Lighting	Yes
Connectivity	USB
Series	Q Series
Brand	Bernina
Automatic Thread Cutter	Yes
Speed Control	Yes
Stitch Regulation	Yes
LCD Screen	Yes
Warranty	Varies by region, consult your local Bernina dealer.
