Beta RR 50 cc ENDURO User Manual

1
GENERAL INFORMATION
15
GB
Key to colours
Bi = White
Ve = Green
Ma = Brown
Vi = Purple
Bl = Blue
Ne = Black
Gi = Yellow
Rs = Red
Ar = Orange
Az = Sky-blue
Ro = Pink
Gr = Grey
LEGEND ELECTRICAL DIAGRAM
1) KEY SWITCH
2) OIL PILOT LAMP
3) NEUTRAL INDICATOR LIGHT
4) HIGH BEAM WARNING LIGHT
5) DIRECTION INDICATOR WARNING LIGHT
6) WHEEL REVOLUTION SENSOR
7) HEADLAMP (DOUBLE FILAMENT BULB)
8) SIDE/TAILLIGHT BULB 12V - 5W
9) ENGINE STOP BUTTON
10) HORN BUTTON
11) HEADLIGHT SELECTOR
12) TURN SIGNAL LAMPS SWITCH
13) L.H. FRONT TURN INDICATOR
14) REGULATOR
15) ENGINE STOP BUTTON
16) OIL LEVEL SENSOR (NOT FITTED ON FACTORY)
17) L.H. REAR TURN INDICATOR
18) R.H. REAR TURN INDICATOR
19) REAR LIGHT LIT BY LED
20) PLATE ILLUMINATION
21) NEUTRAL SENSOR
22) GENERATOR
23) ELECTRONIC CONTROL UNIT
24) SPARK PLUG
25) FRAME EARTH
26) CONDENSATOR 4700 µF
27) BLINKING UNIT
28) R.H. FRONT TURN INDICATOR
29) HORN 12V
30) FRONT BRAKE LIGHT BUTTON

Beta RR 50 cc ENDURO Specifications

General

Brand	Beta
Model	RR 50 cc ENDURO
Category	Motorcycle
Language	English
