3
ADJUSTMENTS
37
GB
ADJUSTMENT OF GAS
CLEARANCE
Whenever the accelerator shows unloaded
travel exceeding 3 mm, measured from the
edge of the handle, you should adjust it by
means of carburettor register B.
ADJUSTING THE FORK
(FACTORY)
The hydraulic rebound damper determines
the behaviour of the telescopic fork during
extension and can be adjusted by means
of screw 1. Turning the screw clockwise in-
creases the action of the rebound damper;
turning it anticlockwise decreases the ac-
tion of the rebound damper.
For standard calibration, refer to page
11.
ADJUSTING THE SPRING
PRELOAD (FACTORY)
Spring preload is adjusted by means of
screw 2. Turning clockwise will increase
the preload, while rotating counter- clock-
wise decreases the preload.
For standard calibration, refer to page
11.
1
2
