4
CHECKS AND MAINTENANCE
40
GB
KEY TO SYMBOLS
Tightening torque
Threadlocker Medium
Grease
1
3
2
GEARBOX OIL
CHECK
Hold the vehicle upright.
Remove screw 2: the oil must arrive at the
lower edge of the hole.
Remove filler cap 1 and top up with fresh
oil.
When the operation is completed, screw
on cap 1 and screw 2.
REPLACEMENT
Always renew the oil while the engine
is hot:
- Place a container under the engine
- Unscrew filler cap 1 and drain plug 3
- Empty the crankcase completely
- Close plug 3
- Pour in 850 gr. / 820 cc of oil
- Verify the level as described above
- Screw on filler cap 1 again.
WARNING:
Hot oil can cause severe burns!
WARNING:
Dispose of used oil in compliance with local regulations.
NOTE:
Change the gear box oil after the first 500 km/350 miles. For subsequent oil changes,
follow the instructions given on the chart on page 53, using the lubricants recom-
mended on page 16.
