CB-S / CB-S-UL (E7) 06/2020 page 20/119
Data monitoring and recording: The chamber is regularly equipped with a zero-voltage relay alarm
output (chap. 15.5) and optionally with analog outputs (chap. 20.6) for integration into customer systems.
The chamber is regularly equipped with an Ethernet interface for computer communication, enabling
monitoring via a network. The BINDER APT-COM™ 4 Multi Management Software (option, chap. 20.4)
permits networking of up to 100 chambers and connection to a computer, as well as recording and repre-
senting temperature and CO
2
data.
A data logger independent from the chamber controller (option, chap. 20.5) serves to independently rec-
ord the temperature values, data given out in compliance with FDA guideline 21 CFR part 11.
2.1 Chamber overview
Figure 5: CO
2
incubator CB-S / CB-S-UL (example CB-S 170), closed
(1) Triangle instrument panel with RD4 controller for temperature and CO
2
(2) Door handle
(3) Main power switch
