7 Installation and Set-Up
7.1 SYSTEM SETUP
NOTE: The laser ships with the lithium ion battery pack already installed.
FACILITY REQUIREMENTS:
Electrical Supply: 100V - 240V ~ at 1.5A, 50/60Hz
Environmental: Temperature 15-35 ºC (59-95 ºF), Humidity 10-90%, non-condensing
• Place the unit in a clean, dry, and well-ventilated area; do not cover or block the ventilation
channels. These channels provide an air-flow path to cool the unit.
• Verify the power switch is in the OFF (O) position.
• Epic X will work using either DC power or its rechargeable battery pack:
o DC Power Supply Module: Connect the DC power supply module to the laser console,
attach one end of the power cord to the DC power supply module and plug the other
end of the power cord into a wall outlet.
o Rechargeable Battery: The Epic X is shipped with the battery pack already installed;
to charge the battery pack, connect the power cord of the DC power supply module to
the laser console and plug into a wall outlet. Before first use, fully charge the battery
(at least 3 hours). Once the battery is charged, unplug the power cord from the wall
outlet and the laser console. The laser console will run on battery power alone. To
fully charge the battery, plug the DC power supply module in and then turn the laser
console ON ( I ) at the power switch. The laser console will start to charge and the unit
will go into Sleep mode (the screen is dark) after 5 minutes; if the power supply is
plugged in but the console is turned OFF (O) at the power switch, the battery will still
charge, but at a slower rate.
7.2 THE FIBER OPTIC CABLE
The Epic X ships with the Fiber Optic Cable built into the laser console and cannot be disconnected
from the console
For storage, wind the Fiber Optic Cable in the fiber storage channel around the base of the console
in a counterclockwise direction.
CAUTION: Do not bend the Fiber Optic Cable at a sharp angle, as it can break. Make
sure it is not caught or pinched between the housing and the fiber optic output plug.
