User’s Guide
Receiver CM-5 behavior control program
When received wireless data is 1, it will take forward motion.
When received wireless data is 2, it will take backward motion.
When received wireless data is 3, it will take left turn motion.
When received wireless data is 4, it will take right turn motion.
When received wireless data is 5, it will take dancing motion.
The actual behavior control program is shown below. Refer to
the““Examples\Example(RF control of Walking Droid).bpg” inside the CD. (Before
running, download Examples\Example(Walking Droid).mtn, motion data from the CD.
If the program did not run properly, check the Zigbee ID. Also, for
the“Examples\Example(RF control of Walking Droid).bpg,” it needs
“Examples\Example(Walking Droid).mtn”motion data, so make sure that it has
been downloaded.
107
