46 Parameters
SR(-T)
Parameter Range of values Tolerance
Basic rate 30 ... 100 ppm +/-1.5 ppm
102 ... 195 ppm +/-2.0 ppm
200 ppm +0.0/-3.0 ppm
Basic interval 1000 ms +/-20 ms
Magnet rate 90 ppm +/-1.5 ppm
Magnet interval 664 ms +/-20 ms
Pulse amplitude 0.2 V +/-0.10 V
0.3 ... 7.5 V +20/-25%
Pulse width 0.1 ... 0.4 ms +/-0.04 ms
0.5 ... 1.0 ms +/-0.10 ms
1.25 ... 1.5 ms +/-0.15 ms
Sensitivity
45502-2-1 Delta pulse
0.5 ... 7.5 mV +/-20%
Refractory period 200 ... 500 ms +10/-30 ms
Max. activity rate 80 ... 100 ppm +/-1.5 ppm
105 ... 160 ppm +/-2.0 ppm
High rate protection 200 ppm +20/-0 ppm
Lead impedance 100 ... 200 Ohm +/-50 Ohm
201 ... 2500 Ohm +/-25%
