47
7 Technical Data
Technical Data7365353-ATechnical manual for the implantEvia DR-T, DR, SR-T, SR
Mechanical Characteristics
Measurements for
the housing
The measurements refer to the housing without header.
Radiopaque marker BIO SF
Materials in contact
with body tissue
• Housing: titanium
• Header: epoxy resin
• Sealing plug: silicone
• Coating, if applicable: silicone
Implant W x H x D [mm] Volume [cm
3
] Mass [g]
DR-T 53 x 44.5 x 6.5 12 25
DR 53 x 43 x 6.5 11 26
SR-T 53 x 39 x 6.5 11 24
SR 53 x 39 x 6.5 10 25
(FCC ID: QRIPRIMUS) This transmitter is authorized by rule under the Medical
Device Radiocommunication Service (in part 95 of the FCC Rules) and must not
cause harmful interference to stations operating in the 400.150-406.000 MHz band
in the Meteorological Aids (i.e., transmitters and receivers used to communicate
weather data), the Meteorological Satellite, or the Earth Exploration Satellite Ser-
vices and must accept interference that may be caused by such stations, including
interference that may cause undesired operation. This transmitter shall be used
only in accordance with the FCC Rules governing the Medical Device Radiocom-
munication Service. Analog and digital voice communications are prohibited.
Although this transmitter has been approved by the Federal Communications
Commission, there is no guarantee that it will not receive interference or that any
particular transmission from this transmitter will be free from interference.
FCC Statement
