BIOTRONIK EVIA - Pacing and Sensing SR(-T)

40 Parameters
Pacing and Sensing SR(-T)
Pulse amplitude
and pulse width
Sensitivity
Ventricular capture control
Lead configuration
IEGM recordings
Rates for statistics
Parameter Range of values Standard
Pulse amplitude 0.2 ... (0.1) ... 6.2; 7.5 V 3.0 V
Pulse width 0.1; 0.2; 0.3; 0.4; 0.5; 0.75; 1.0; 1.25;
1.5 ms
0.4 ms
Parameter Range of values Standard
Sensitivity AUTO
0.5 ... (0.5) ... 7.5 mV
AUTO
Parameter Range of values Standard
Ventricular capture control ON; ATM (monitoring only)
OFF
ON
Min. amplitude 0.7 V 0.7 V
Threshold test start 2.4; 3.0; 3.6; 4.2; 4.8 V 3.0 V
Safety margin 0.3 ... (1) ... 1.2 V 0.5 V
Search time Interval; time of day Interval
Interval 0.1; 0.3; 1; 3; 6; 12; 24 h 24 h
Time of day 00:00 ... (15 min) ... 23:45 hh:mm 02:00 hh:mm
Parameter Range of values Standard
Pacing polarity Unipolar; bipolar Unipolar
Sensing polarity Unipolar; bipolar Unipolar
Parameter Range of values
IEGM recordings 20 (quantity); each max. 10 s
Types of IEGM recordings High rate (HR)
Patient triggered (Pt.)
IEGM recording prior to event 0; 25; 50; 75; 100%
IEGM signal Filtered; unfiltered
Parameter Range of values Standard
High rate (HR) 150 ... (5) ... 200 bpm
400; 387 ... 308; 300 ms
180 bpm
333 ms
HF counter 4; 8; 12; 16 8
