53 Technical Data
Transfer sheath for leads with PIN-lock PE lead con-
nector (5 mm) to connect to pacemakers with PEC
sockets (6 mm)
Implant with NBG encoding and name of compatible
leads (example)
Silicone-coated implant with NBG encoding and des-
ignation of the compatible leads (example)
Screwdriver
Position of connector ports in the header (example)
Unipolar IS-1 connector
Bipolar IS-1 connector
A Atrium
V Ventricle
UNI/BI Unipolar/bipolar configuration
V
p
V
s
Ventricular pace
Ventricular sense
A
p
A
s
Atrial pace
Atrial sense
DDDR
A
IS-1
