BP-007 User’s Manual
- 28 -
UNI-DIR unidirectional or bidirectional
PAPER
WIDTH
76 mm; 57.5
mm
Specify the bill width of 76mm or 57.5mm.
INTERFACE RS-232 Specify the interface type. Only for Serial
interface model
BAUD RATE 9600 bps;
19200 bps
Specify the printer serial data transfer rate. Only for Serial
interface model
PARITY
CHECK
NO; EVEN;
ODD
Specify the parity bit for serial data transfer. Only for Serial
interface model
DATA BIT
LENGTH
8 BITS Specify the serial data bits. Only for Serial
interface model
STOP BIT 1 BIT Specify the serial data transfer stop bit. Only for Serial
interface model
HANDSHAKE DTR/DSR;
XOFF/XON
Specify the protocol of printer serial data
transfer as software control (XON/XOFF) or
hardware control (DTR).
Only for Serial
interface model
3.2.3 Parameter Settings
BP-007 supports the function of online-aptitude parameter settings, which can be set in the PC with the
driver installed in.
The concrete setting steps are shown as follows:
1. Make sure that the computer and the printer are connected with a cable and both the computer and
the printer are turned on, the printer should be in normal working condition as well.
2. Click “Start” → “Settings” → “Printers”.
3. Right click “BP-007”, select “Properties”.
4. Click “Printer settings” in the property page.
