BP-007 User’s Manual
- 4 -
Note: You must use the proper cash drawer. Manufacturer will not honor warranty when using
improper cash drawer.
2.3.2 Connecting the Parallel Cable
1. Make sure that the computer and the printer are both turned off, connect the parallel cable to the
interface of the printer, and fasten the wire clips as shown in Figure 2-3.
2. Connect the other end of the cable to the computer’s parallel interface, and tighten the screws on
both sides.
2.3.3 Connecting the USB Cable
1. Plug the USB cable A end (flat shape) into the computer's USB interface.
2. Plug the USB cable B end (square shape) into the printer's USB interface. (As shown in figure
2-4)
Caution: Don't impact the plug after connecting to the USB cable.
Fi
