BP-007 User’s Manual
- 39 -
5.3 Auto-cutter Specification
BP-007 is equipped with an auto-cutter, which parameter is shown as table A-4:
Table A-4 Auto-cutter Specification
Item Specification
Paper width 85mm (max.)
Cuttable thickness
Paper thickness: 65～75 µm
Cutting mode
Full cut or partially cut leaving point (one
point, 2mm)
Drive voltage (V) Motor: 24±2.4, detector: 3.3±0.165
Startup current (A) 1.2 (max.)
Operating time (second/ cut period) 500 (max.)
Cutting frequency (cuts/minute) 30 (max.)
Physical dimensions (length × width × height) (mm) 100×52×15
