Digital Power Meter Model 5000-XT
12
Performing a Screen Shot
1. Press and hold <.> for two seconds will perform a screen shot of the current
screen on the DPM.
2. Select OK to confirm the screen shot.
Note: The image file name will be displayed.
Directional Power Sensor (DPS)
Setting Scale
Note: The Bird DPS uses Bird Plug-In Elements. These are labeled
with a max power and a frequency range.
Note: The transmitter frequency should be within the
element range.
Note: Forward and Reflected full scale power must be entered
manually.
1. Press Scale.
2. Select the power units (W, mW or kW) with up and down arrow keys.
3. Enter the maximum power of the element in the forward element socket
using the numeric keypad and <.> key.
Note: The element’s max power is listed on the element name-
plate.
4. Press OK.
WARNING
RF voltage may be present in RF element socket. Keep element in socket
during operation.
